MidNite Solar MNPowerFlo5 5.12 kWh 48V U3 Server Rack Mount LFP Battery

Overview

The MidNite Solar MNPowerFlo5 is a high-performance lithium iron phosphate battery designed for efficient and scalable energy storage. It uses EVE A grade LiFePO4 cells and offers a 15 year lifespan with up to 6000 charge cycles, delivering durable and reliable storage. The battery supports parallel connections of up to 16 units, providing a total capacity of 81 kWh. It is compatible with the MidNite TheOne inverter and allows easy plug-and-play integration with other MNPowerFlo5 batteries.

Benefits

• Reliable energy storage with 5.12 kWh capacity per unit expandable to 81 kWh
• Long cycle life of 6000 cycles and a 15 year design life
• Compatibility with MidNite TheOne inverter and other MNPowerFlo5 units
• Built-in smart battery management system for real-time monitoring
• Space-saving rack-mount design suitable for residential and commercial use
• Certified for safety under UL 1973, UL 9540A, and UL 9540 standards

Features

• 15 year design life with 6000 charge cycles at 77 degrees Fahrenheit
• Advanced lithium iron phosphate chemistry for safety and efficiency
• Expandable up to 16 units in parallel for scalable storage
• Modular rack-mount design for easy installation and expansion
• Fully compatible with MidNite TheOne inverter and supports Pylon Protocol communication
• Automatic battery addressing enables plug-and-play setup without manual configuration
• Built-in battery management system monitors voltage, current, and temperature for each cell
• Passive balancing and advanced control methods optimize performance and longevity
• Operational temperature range from minus 4 degrees to 113 degrees Fahrenheit
• UL certification ensures safe use in both on-grid and off-grid environments
• Stackable rack system with brackets for secure, space-saving deployment

Specifications

• Nominal Voltage: 51.2 volts
• Nominal Capacity: 100 amp hours
• Total Energy Storage: 5.12 kilowatt hours per unit
• Cycle Life: 6000 cycles at 77 degrees Fahrenheit
• Operating Temperature Range: minus 4 to 113 degrees Fahrenheit
• Dimensions: 17.7 inches length, 17.4 inches width, 5.2 inches depth
• Weight: 96.5 pounds
• UL Listings: UL 1973, UL 9540A, UL 9540
• Communication Interfaces: CAN, RS485, RS232 supporting Pylon Protocol
• Scalability: supports up to 16 batteries in parallel
• Nominal Charging Current: 75 amps
• Maximum Discharging Current: 100 amps
