Reliable Power, No Complications

If you want a battery that delivers optimal performance without the worry of breakdowns, the ALPHA 4 LITE is the 24V 200Ah LiFePO4 solution you need. Crafted with RICH SOLAR’s premium materials and offering 2560Wh of energy, this battery ensures you’ll have reliable power wherever your adventures take you.

Featuring a lightweight, durable design with individually fused lithium cells, the ALPHA 4 LITE is the straightforward, high-performance battery for those ready to go without hassle.

Specifications
BATTERY

  • Nominal Voltage: 25.6V
  • Nominal Capacity: 100Ah
  • Minimum Capacity: 99.5Ah
  • Cycle Life: Over 4000 cycles

Operating Details

  • Capacity: 100Ah
  • Energy: 2560 Watt Hours
  • Charge Voltage: 28.8V
  • Continuous Discharge Current: 100A
  • Self Discharge Rate: Less than 5% per month

Temperature Ranges

  • Charge Temperature: 32°F to 131°F (0°C to 55°C)
  • Discharge Temperature: -4°F to 140°F (-20°C to 60°C)
  • Storage Temperature: 14°F to 113°F (-10°C to 45°C), 90% RH max (for more than 3 months)

Physical Specifications

  • Dimensions (L x W x H): 20.9 x 8.1 x 8.5 in
  • Weight: 52.9 lb

Battery Management System (BMS) Operation

  • Overcharge Protection:

    • Overcharge Detection Voltage: 3.75V ± 0.05V
    • Delay Time for Overcharge Detection: 1000ms ± 500ms
    • Overcharge Recovery Voltage: 33.55V ± 0.05V

  • Over-Discharge Protection:

    • Over-Discharge Detection Voltage: 2.20V ± 0.08V
    • Delay Time for Over-Discharge Detection: 1000ms ± 500ms
    • Over-Discharge Recovery Voltage: 2.70V ± 0.10V

  • Short Circuit Protection: Yes

Warranty: 5-Year Warranty

RICH SOLAR

ALPHA 4 LITE | 24V 100Ah LiFePO4 Battery | Fast-Charging 24V Lithium Battery for RVs, Trailers, Vans, Boats, Off-Grid, Backup | 4,000 Lifetime Cycles | Best Value

SKU RS-B24100
$941.16
$799.99

Reliable Power, No Complications

If you want a battery that delivers optimal performance without the worry of breakdowns, the ALPHA 4 LITE is the 24V 200Ah LiFePO4 solution you need. Crafted with RICH SOLAR’s premium materials and offering 2560Wh of energy, this battery ensures you’ll have reliable power wherever your adventures take you.

Featuring a lightweight, durable design with individually fused lithium cells, the ALPHA 4 LITE is the straightforward, high-performance battery for those ready to go without hassle.

Specifications
BATTERY

  • Nominal Voltage: 25.6V
  • Nominal Capacity: 100Ah
  • Minimum Capacity: 99.5Ah
  • Cycle Life: Over 4000 cycles

Operating Details

  • Capacity: 100Ah
  • Energy: 2560 Watt Hours
  • Charge Voltage: 28.8V
  • Continuous Discharge Current: 100A
  • Self Discharge Rate: Less than 5% per month

Temperature Ranges

  • Charge Temperature: 32°F to 131°F (0°C to 55°C)
  • Discharge Temperature: -4°F to 140°F (-20°C to 60°C)
  • Storage Temperature: 14°F to 113°F (-10°C to 45°C), 90% RH max (for more than 3 months)

Physical Specifications

  • Dimensions (L x W x H): 20.9 x 8.1 x 8.5 in
  • Weight: 52.9 lb

Battery Management System (BMS) Operation

  • Overcharge Protection:

    • Overcharge Detection Voltage: 3.75V ± 0.05V
    • Delay Time for Overcharge Detection: 1000ms ± 500ms
    • Overcharge Recovery Voltage: 33.55V ± 0.05V

  • Over-Discharge Protection:

    • Over-Discharge Detection Voltage: 2.20V ± 0.08V
    • Delay Time for Over-Discharge Detection: 1000ms ± 500ms
    • Over-Discharge Recovery Voltage: 2.70V ± 0.10V

  • Short Circuit Protection: Yes

Warranty: 5-Year Warranty
$941.16
$799.99
