23ZERO Kabari XL – Wedge Hardshell Rooftop Tent

The Kabari XL Wedge Hardshell Rooftop Tent combines practicality and innovation with integrated dual T-slot rails along the upper and lower edges, offering versatile mounting options for accessories and a built-in power module. Designed to comfortably sleep two adults, it includes a ladder, mounting hardware, condensation mat, rainfly poles, dual LED lights, and a comfortable 2.75” rebound foam mattress, all wrapped in a sleek black exterior.

Sleep soundly with the insulated grey cotton-poly topper and Light Suppression Technology (LST), which creates a cool, dark environment ideal for any terrain. Access is easy via three entrances, and the durable ECO13B fabric provides excellent weather resistance, making it ideal for off-road adventures.

Stay organized with a spacious six-pocket gear loft featuring a clear tablet section and side pockets, plus a boot bag with multiple compartments. Enjoy 360-degree views and fresh air through four large windows and three entrances, all fitted with preinstalled ladder brackets.

Rapid setup and takedown are effortless thanks to the external X-frame design, which minimizes fabric tucking. The low-profile wedge shell improves aerodynamics and reduces wind drag.

Additional features include two USB 5V LED lights with adjustable brightness, heavy-duty latches, a 5/8” rubber gasket for weatherproofing, and an enhanced closing mechanism with bungee assist.

The integrated roof bar system supports a variety of gear with two cross bars (55” W x 2.875” L x 0.75” H) and pre-drilled mounting points. The power module includes 12V, USB-A, and USB-C ports wired to an externally mounted SB50 Anderson plug (power source not included).

Overview & Dimensions

The Kabari XL is a spacious wedge-style hardshell rooftop tent built for elevated comfort and off-grid capability. Featuring premium ECO13B recycled fabric, integrated power ports, and Light Suppression Technology (LST), it delivers a restful, dark-sleep experience—no matter where the trail leads.

• Mounting Footprint: 55" W x 84.5" L x 8.5" H (including mounting rails)
• Mounting Weight: 202 lb
• Sleeping Footprint: 49.5" W x 79" L
• Internal dimensions: 50" W x 80" L x 53" H (thirteen inches at the foot)
• Sleeps: 2 Adults
• Seasons: 4 Season

Mounting Kit Includes

• Four (4) rubber-coated mounting plates
• Ten (10) sliding mounting plate sets (plate, bolt, washer, nylock nut) with 1.75” and 2.5” bolts (only eight sets needed)
• 10mm and 13mm wrenches
• Allen wrench
• Two (2) USB LED lights with cables
• Four (4) rail end caps
• All contained in a zippered bag

Also Included

• Ladder with storage bag
• Four (4) rainfly poles (40” L) with storage bag
• Two roof cross bars
• Four roof cross bar mounting plates
• Sixteen bolt/nut sets for cross bar installation
• Preinstalled hardware: four (4) boot bag hooks, four (4) latches, two (2) ladder hooks, and four (4) window pole mounts

Rack Requirements

• Verify your vehicle’s maximum roof load capacity as specified by the manufacturer.
• Consult with the rack manufacturer or retailer to check the load limit of your roof rack or truck bed rack, especially for off-road use.
• Understand that the maximum allowable weight you can safely add to your vehicle’s roof or cargo area may vary depending on the make and model of the vehicle, as well as any aftermarket additions such as roof racks or bars.
