EG4 12000XP Off-Grid Solar Inverter | EG4-12000XP

EG4 12000XP Off-Grid Solar Inverter

The EG4 12000XP is a powerful, all-in-one off-grid inverter designed for reliable performance and durability. Whether operating fully off-grid or integrated with grid power, it offers versatile solutions for both residential and commercial applications.

Key Features:

• High Input Voltage (480VDC): Supports high-voltage input, reducing the need for extensive cabling and allowing up to 24kW PV input without a combiner box.
• Dual MPPT Design: Optimizes solar energy utilization, ensuring efficiency and stability under varying sunlight conditions.
• Plug-in Wi-Fi Capability: Remotely monitor and adjust settings through the EG4 app or monitoring system, giving you control from any location.
• Closed-Loop Communication: Seamlessly integrates with EG4 48V batteries and other compatible brands for enhanced system performance and safety.
• Rapid Shutdown Compliance: NEC 690.12-ready rapid shutdown (RSD) capabilities ensure compliance and peace of mind in critical situations.

Performance Highlights:

• 12kW Power Output with Surge Capacity up to 18kW: Provides reliable power for heavy-duty appliances and equipment in off-grid settings.
• Expandable Power Options: Parallel up to six units for a scalable 72kW system, allowing flexibility to meet future power demands.
• High Efficiency: With 99% MPPT efficiency, the inverter maximizes energy harvest while minimizing energy loss.

Technical Specifications:

• AC Input: 120/240VAC | 50/60 Hz
• Max Continuous Output: 12kW
• Surge Capacity: 18kW (5 seconds)
• Battery Compatibility: Lead-Acid/Lithium, with a minimum recommendation of 400Ah per inverter
• Operating Temperature: 32°F – 113°F (0°C – 45°C)
• Protection Features: PV Reverse Polarity, Over-Voltage, and Surge Protection
• Warranty: 5 years

Ideal Applications:

• Residential Off-Grid Living: Perfect for homes aiming to break free from grid dependence.
• Remote Worksites and Cabins: Provides a steady, reliable power supply for isolated locations.
• Commercial and Industrial Use: Suitable for demanding off-grid power requirements.

With high output power, advanced safety features, and remote management, the EG4 12000XP is an efficient, durable, and scalable solution to meet your off-grid energy needs.
