Product Description
Key Features
- Supports high photovoltaic (PV) input voltage
- Low-frequency pure sine wave output for stable performance
- Versatile split-phase output functionality
- Built-in MPPT solar charge controller
- Heavy-duty pure copper transformer construction
- User-selectable grid or solar input priority
- WiFi-enabled remote monitoring capability
- Comprehensive protection against overload, short circuit, and deep discharge
- CAN and RS485 communication protocols for BMS integration
- Advanced LCD interface for detailed system monitoring
- LED indicators for charging status, system operation, and fault alerts
- Compact design with dependable long-term reliability
Ideal Applications
- 12V battery-based power systems
- Residential solar energy installations
- Medium-scale off-grid setups
- Backup and emergency power solutions
- Self-consumption and energy independence systems
Inverter Technical Specifications
GTIN-12 (UPC): 850061252418
Battery Voltage: 12V DC
Rated Output Power: 3000 VA / 2400 W
Peak Power Output: 5500 W
Parallel Operation: Supported
Nominal Output Voltage (RMS): N/A
Output Frequency: 60 Hz ± 0.1%
AC Voltage Regulation: 120 VAC ± 2%
Peak Inverter Efficiency: 94%
Output Waveform: Pure Sine Wave
Transfer Time: N/A
Nominal AC Voltage: 120 VAC
Selectable Voltage Range: 90–140 VAC
Auto-Sensing Frequency Range: 45–65 Hz
Maximum Charging Current: 120 A
Maximum PV Array Power: N/A
Maximum PV Charge Current: N/A
Maximum PV Open Circuit Voltage: N/A
Maximum Efficiency: N/A
MPPT Trackers / Strings per Tracker: N/A
MPPT Operating Voltage Range: N/A
Weight: 42 lbs
Depth: 5.8 in
Width: 10.9 in
Height: 21.1 in
Operating Temperature: N/A
Maximum Operating Altitude: N/A
Ingress Protection Rating: N/A
