The MRCOOL® DIY® 24K BTU 5th Generation Ductless Mini Split Condenser – 230V is engineered to simplify HVAC installation, making it an excellent choice for DIY enthusiasts. Designed for spaces between 750 and 1,000 sq. ft., this system requires no specialized tools or professional HVAC experience.
Thanks to the pre-charged 25-foot QuickConnect® line set, installation is straightforward—no vacuuming required. The durable DIYPRO® cable replaces traditional electrical conduit, offering enhanced protection against weather, animals, and accidental damage during yard work.
Control the system with ease using the included remote, the SmartHVAC app on iOS or Android, or go hands-free with Amazon Alexa and Google Assistant compatibility. For homes in coastal regions, the Gold Fin Condenser provides added corrosion resistance, ensuring long-term reliability.
The unit includes features designed to maximize efficiency and convenience, such as:
-
Timer function for energy management
-
Auto mode to maintain your preferred temperature
-
Auto-restart that restores previous settings after a power outage
-
Anti-mildew function to prevent moisture buildup in the air handler
Built to last, the 5th Gen MRCOOL® DIY® Mini Split comes with an industry-leading warranty:
Combining easy installation with advanced smart features, this system delivers reliable comfort and long-term performance.
Product Specifications:
| BRAND NAME |
MRCOOL |
| SERIES |
DIY 5th Gen Single-Zone Mini-splits |
| MODEL |
DIY-36-HP-C-230D25-O |
| GTIN |
840255586986 |
| UPC |
840255586986 |
| SHORT DESCRIPTION |
MRCOOL® 36k DIY 5th Generation Mini-Split Condenser 230v |
| SEER2 |
18 |
| EER2 |
8.5 |
| HSPF2-4 |
8.5 |
| HSPF2-5 |
6.5 |
| TONNAGE |
3 |
| COOLING CAPACITY (BTU) |
36000 |
| HEATING CAPACITY (BTU) |
36000 |
| VOLTAGE (V) |
208/230 |
| PHASE |
1 |
| CYCLE |
60 |
| MAX FUSE BREAKER (A) |
35 |
| MIN CIRCUIT AMPACITY (A) |
33 |
| COLOR |
White |
| ZONE CAPACITY |
1 |
| REFRIGERANT TYPE |
R-454B |
| REFRIGERANT VOLUME (OZ) |
109.7 |
| DECIBEL RATING (DBA) |
60.5 |
| INVERTER |
DC |
| LINE SET LENGTH |
25 |
| MAX LINESET LENGTH (FT) |
213.2 |
| LIQUID LINE SIZE |
3/8 |
| SUCTION LINE SIZE |
5/8 |
| COMPRESSOR MOTOR TYPE |
Rotary |
| AUXILIARY HEATER INCLUDED |
No |
| AUXILIARY HEATER AVAILABLE |
No |
| FAN ONLY OPTION |
Yes |
| QUIET MODE |
Yes |
| AUTO COOL |
Yes |
| WIFI COMPATIBILITY |
Yes |
| APP COMPATIBILITY |
Yes |
| WORKS WITH IOS |
Yes |
| WORKS WITH ANDROID |
Yes |
| UL LISTED |
Yes |
| ETL LISTED |
Yes |
| AHRI CERTIFIED |
Yes |
| REGISTERED WARRANTY |
Extended Limited Lifetime* |
| BASE PARTS WARRANTY |
5 |
| BASE COMPRESSOR WARRANTY |
7 |
| HAS BATTERIES |
Yes |
| CONTAINS ELECTRONICS |
Yes |
| CONTAINS CHEMICALS |
Yes |
| CONTAINS AEROSOL |
Yes |
| CONTAINS COMPRESSED GAS |
Yes |
| PROPOSITION 65 WARNING |
Yes |
| NET DEPTH (IN) |
16.14 |
| NET HEIGHT (IN) |
31.89 |
| NET WIDTH (IN) |
37.24 |
| NET WEIGHT (LBS) |
152.12 |
| GROSS DEPTH (IN) |
19.88 |
| GROSS HEIGHT (IN) |
37.01 |
| GROSS WIDTH (IN) |
42.91 |
| GROSS WEIGHT (LBS) |
183.42 |
