The included DIYPRO® cable simplifies installation by eliminating the need for traditional electrical conduit, while providing enhanced durability and protection against weather, wildlife, and other outdoor elements. Controlling your comfort is effortless, thanks to multiple control options: use the wireless remote, the SmartHVAC app for iOS and Android devices, or enjoy hands-free convenience with Amazon Alexa or Google Assistant.
The system's Follow Me feature enhances comfort by detecting the location of the remote and adjusting the temperature accordingly, ensuring balanced airflow throughout your space. To further improve your indoor environment, Dry Mode helps reduce excess humidity and maintain a comfortable climate.
Built to last, the Gold Fin® Condenser on the outdoor unit offers excellent corrosion resistance, making it especially well-suited for coastal applications. Backed by industry-leading warranties—including a limited lifetime warranty, 7 years on the compressor, and 5 years on parts—the MRCOOL® DIY® system delivers reliable, year-round comfort with advanced features and truly simple installation.
Product Specifications:
| BRAND NAME |
MRCOOL |
| SERIES |
DIY 5th gen Single-Zone Mini-splits |
| MODEL |
DIY-24-HP-WMAH-230D25-O |
| GTIN |
840255587051 |
| UPC |
840255587051 |
| SHORT DESCRIPTION |
MRCOOL® 24k DIY 5th Generation Mini-split Air Handler 230v |
| TONNAGE |
2 |
| VOLTAGE (V) |
208/230 |
| PHASE |
1 |
| CYCLE |
60 |
| MAX FUSE BREAKER (A) |
15 |
| MIN CIRCUIT AMPACITY (A) |
3 |
| MOUNT TYPE |
Wall |
| COLOR |
White |
| MAX COVERAGE AREA |
1050 sqft |
| DECIBEL RATING LOW (DBA) |
20 |
| DECIBEL RATING HIGH (DBA) |
54 |
| NUMBER OF SPEEDS |
5 |
| OSCILLATION |
Yes |
| LIQUID LINE SIZE |
3/8 |
| SUCTION LINE SIZE |
5/8 |
| FILTER TYPE |
Reusable |
| AUXILIARY HEATER INCLUDED |
No |
| AUXILIARY HEATER AVAILABLE |
No |
| FAN ONLY OPTION |
Yes |
| QUIET MODE |
Yes |
| AUTO COOL |
Yes |
| WIFI COMPATIBILITY |
Yes |
| APP COMPATIBILITY |
Yes |
| WORKS WITH IOS |
Yes |
| WORKS WITH ANDROID |
Yes |
| REMOTE CONTROL INCLUDED |
Yes |
| UL LISTED |
Yes |
| ETL LISTED |
Yes |
| ENERGY STAR CERTIFIED |
Yes |
| AHRI CERTIFIED |
Yes |
| REGISTERED WARRANTY |
Extended Limited Lifetime* |
| BASE PARTS WARRANTY |
5 |
| BASE COMPRESSOR WARRANTY |
7 |
| HAS BATTERIES |
Yes |
| CONTAINS ELECTRONICS |
Yes |
| CONTAINS CHEMICALS |
Yes |
| CONTAINS AEROSOL |
Yes |
| CONTAINS COMPRESSED GAS |
Yes |
| PROPOSITION 65 WARNING |
Yes |
| NET DEPTH (IN) |
8.9 |
| NET HEIGHT (IN) |
13.19 |
| NET WIDTH (IN) |
42.52 |
| NET WEIGHT (LBS) |
35.93 |
| GROSS DEPTH (IN) |
17.68 |
| GROSS HEIGHT (IN) |
14.29 |
| GROSS WIDTH (IN) |
46.73 |
| GROSS WEIGHT (LBS) |
49.82 |
